The PCE 125 Amp 5 Pole Plug IP67 is a heavy-duty industrial plug designed for high-power electrical connections in demanding environments such as factories, construction sites, generators, and temporary power distribution systems. It is manufactured with robust PA6 industrial thermoplastic housing, providing excellent durability, impact resistance, and insulation.
| Specification | Details |
|---|---|
| Brand | PCE |
| Product Type | Industrial Plug |
| Rated Current | 125 Amp |
| Number of Poles | 5 Pole (3P + N + E) |
| Rated Voltage | 380 – 415 V AC |
| Frequency | 50 / 60 Hz |
| Protection Rating | IP67 (Dustproof & Waterproof) |
| Standard | IEC 60309-1 / IEC 60309-2 |
| Earth Position | 6h |
| Housing Material | PA6 Industrial Thermoplastic |
| Contact Material | Brass / Nickel-Plated Brass |
| Connection Type | Screw Terminal |
| Cable Entry | Gland Nut with Strain Relief |
| Cable Size | 16 – 50 mm² |
| Cable Diameter | Approx. 22.5 – 50 mm |
| Operating Temperature | −25°C to +40°C |
| Identification Color | Red (Three-Phase) |
| Application | Industrial machinery, generators, event power, marine and heavy-duty electrical installations |
High-power 125A industrial connector
IP67 waterproof and dustproof protection
Durable PA6 thermoplastic housing for long service life
Secure screw terminal cable connection
Compatible with IEC 60309 industrial sockets
Ideal for industrial, marine, construction, and temporary power systems
