₨23,100
Pick up from the Woodmart Store
To pick up today
Free
Courier delivery
Our courier will deliver to the specified address
2-3 Days
Free
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
Warranty 1 year
Free 30-Day returns
Payment Methods:
The PCE 125A 5 Pole Wall Socket IP67 is a heavy-duty industrial socket designed for high-power electrical connections in demanding environments such as factories, construction sites, power plants, and outdoor installations.
Heavy-duty industrial wall-mounted socket
125 Amp high current capacity
5-pole configuration (3P + N + Earth)
IP67 waterproof and dustproof protection
Durable PC/ABS thermoplastic housing
Secure screw terminal connection
Compatible with industrial CEE plugs
Designed according to IEC 60309 standards
| Specification | Details |
|---|---|
| Rated Current | 125 Amp |
| Rated Voltage | 200 – 415 V AC |
| Frequency | 50 / 60 Hz |
| Number of Poles | 5 Pole (3P + N + PE) |
| Clock Position | 6h |
| Protection Rating | IP67 (Dustproof & Waterproof) |
| Mounting Type | Wall Mounted / Surface Mounted |
| Housing Material | PC/ABS Industrial Thermoplastic |
| Contact Material | Brass (CuZn) |
| Connection Type | Screw Terminal |
| Wire Capacity | Flexible: 16–50 mm² / Solid: 16–70 mm² |
| Operating Temperature | −25°C to +40°C |
| Temperature Resistance | Up to 80°C |
| Standard Compliance | IEC 60309-1 / IEC 60309-2 |
| Identification Color | Red (for 400V 3-phase systems) |
Industrial power distribution
Heavy machinery connections
Construction sites
Manufacturing plants
Outdoor electrical installations
Generator and temporary power systems
