Schneider GV2ME22 3P MPCB Breaker price in Pakistan is Rs 17,000/-.
TeSys GV motor circuit breaker, 3 poles (3P), 25A/690V, for 3-phase motor applications 11kW@400V. It provides a thermal-magnetic protection with a thermal setting range 20-25A, magnetic tripping at 13xIn, high breaking capacity Icu 15kA@400V. Connection by screw clamp terminals. Start-stop control by push-button guaranteed for 100 000 cycles AC-3. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine, ATEX), Green Premium compliant (RoHS/REACh).
|
Range
|
tesys deca
|
|
product name
|
tesys gv2 / tesys deca
|
|
product or component type
|
motor circuit breaker
|
|
net weight
|
0.26 kg
|
|
device short name
|
gv2me
|
|
device application
|
motor protection
|
|
trip unit technology
|
thermal-magnetic
|
|
poles description
|
3p
|
|
network type
|
ac
|
|
utilization category
|
category a conforming to iec 60947-2
|
|
network frequency
|
50/60 hz conforming to iec 60947-4-1
|
|
35 mm symmetrical din rail
|
clipped
|
|
panel
|
screwed (with adaptor plate)
|
|
control type
|
push-button
|
|
rated current [in]
|
25 a
|
|
thermal protection adjustment
|
20…25 a conforming to iec 60947-4-1
|
|
magnetic tripping current
|
327 a
|
|
conventional free air thermal current [ith]
|
25 a conforming to iec 60947-4-1
|
|
rated operational voltage [ue]
|
690 v ac 50/60 hz conforming to iec 60947-2
|
|
rated insulation voltage [ui]
|
690 v ac 50/60 hz conforming to iec 60947-2
|
|
rated impulse withstand voltage [uimp]
|
6 kv conforming to iec 60947-2
|
|
phase failure sensitivity
|
yes conforming to iec 60947-4-1
|
|
suitability for isolation
|
yes conforming to iec 60947-1 § 7-1-6
|
|
power dissipation per pole
|
2.5 w
|
|
mechanical durability
|
100000 cycles
|
|
electrical durability
|
100000 cycles for ac-3 at 415 v in / 100000 cycles for ac-3e at 415 v in
|
|
standards
|
en/iec 60947-2 / en/iec 60947-4-1
|
|
ik degree of protection
|
ik04
|
|
ip degree of protection
|
ip20 conforming to iec 60529
|
|
climatic withstand
|
conforming to iacs e10
|
|
ambient air temperature for storage
|
-40…80 °c
|
|
fire resistance
|
960 °c conforming to iec 60695-2-11
|
|
ambient air temperature for operation
|
-20…60 °c
|
|
operating altitude
|
2000m
|
Overview
| No of Pole |
3 Pole |
|---|---|
| Ampere Rating |
20–25 A |
