Terasaki EPC 3 Pole MCB Breaker Price in Pakistan is RS. 18,500
The Terasaki EPC 3 Pole Miniature Circuit Breaker offers reliable electrical protection with a breaking capacity of 6000A DC and AC. Available in ampere ratings from 6 to 63, it caters to various electrical needs. Featuring characteristics B, C, and D, it ensures adaptability to different applications. With a compact device height of 76mm and a frame size of 81mm, it fits easily into installations with limited space. The terminal protection feature keeps fingers and hands safe during installation and operation, while the open-mouthed/lift terminals facilitate easy wiring. Designed for DIN rail mounting, installation is convenient and secure. Compliant with IEC 60898-1 and IEC 60947-2 standards, it ensures adherence to international safety regulations. With a tripping temperature range from 0.5 to 40 degrees Celsius and terminal capacity ranging from 1 to 25mm2, it offers reliable performance in various environments. Ideal for residential, commercial, and industrial applications, the Terasaki EPC circuit breaker provides efficient and dependable electrical protection.
|
Type
|
miniature circuit breaker
|
|
breaking capacity
|
ics=icn; 6000a dc; 6000a
|
|
rated voltage
|
230v / 400v
|
|
ampere
|
6, 10, 16, 20, 32, 40, 50 & 63.
|
|
characteristics
|
b, c & d
|
|
device height
|
76mm
|
|
frame size
|
81mm
|
|
socket size
|
17.5mm per pole
|
|
degree of protection
|
ip20
|
|
number of poles
|
triple pole
|
|
terminal protection
|
finger and hand touch safe
|
|
upper and lower terminals
|
open-mouthed/ lift terminals
|
|
mounting
|
din rail mount
|
|
tripping temperature
|
5-40
|
|
ampere rating
|
10ka – 16ka.
|
|
design according to iec
|
iec 60898-1 / iec 60947-2
|
|
terminal capacity
|
1-25mm2
|
Overview
| Ampere Rating |
10A ,16A ,20A ,32A ,40A ,50A ,63A ,6A |
|---|---|
| No of Pole |
3 Pole |
